| Retail Price |
395 |
| Designed in |
USA |
| Manufactured In |
USA |
| First Year |
1968 |
| Last Year |
1970 |
| Gold Face |
Yes |
| Channels |
Two (dual mono block) |
| Speaker Connections |
Two |
| Power Consumption |
240 watts |
| Independent Power Supplies |
Yes |
|
| RMS Power Per Channel |
70 @ 4 ohms, 60 @ 8 ohms, 40 @ 16 ohms |
| Damping Factor @ Load Impedance |
> 150 with 8 ohm load |
| Total Harmonic Distortion (THD) |
0.1%, typically below 0.03% with 8-ohm load |
| Power Bandwidth |
8 Hz to 60 KHz |
| Frequency Response |
10 Hz to 60 KHz +/- 1 dB |
| Hum and Noise |
90 dB below 60 watts into 8 ohms |
| Input Impedance |
100 Kohms |
| Input Sensitivity for Full Output |
1 volt RMS |
|
